Suitable For

Type:

F Series

Model:

F250 4x4

Year:

2001 to 11/2006

Detail:

4.2L 6 Cyl Turbo Diesel, 7.3L Diesel

Download Catalogue Page

Coil Springs: Sold in Pairs. Torsion Bars: Sold in Pairs. Prices are subject to change without notice. *Raised Height Measurements are Listed as a Guide Only

Front

Leaf Spring

When Fitting the Below Springs, U-Bolt Part Number UB19-921K Must be Fitted.

7.3L Turbo Diesel

Left Hand Side
Raised Height (50mm Lift)
6 Leaf Multi Leaf Spring
Replaces 2 Leaf Parabolic

Part Number

FORD-010-F LH

Availability

Right Hand Side
Raised Height (50mm Lift)
6 Leaf Multi Leaf Spring
Replaces 2 Leaf Parabolic

Part Number

FORD-010-F RH

Availability

4.2L Turbo Diesel

Left Hand Side
Raised Height (50mm Lift)
5 Leaf Multi Leaf Spring
Replaces 2 Leaf Parabolic

Part Number

FORD-011-F LH

Availability

Right Hand Side
Raised Height (50mm Lift)
5 Leaf Multi Leaf Spring
Replaces 2 Leaf Parabolic

Part Number

FORD-011-F RH

Availability

Shock Absorber

Twin Tube Nitro-Gas

Part Number

GS59-651A

Availability

Spring & Shackle Bush Kit

Front of Front

Part Number

PB19-1504

Availability

Rear of Front

Part Number

PB19-1505

Availability

U-Bolt Kit

Kit Contains:
2 x UB19-921

Part Number

UB19-921K

Availability

Adjustable Panhard Rod

Complete with Bushes

Part Number

PR19-1400

Availability

Air Bag Kit

Bellows Type

Part Number

RR4557

Availability

Rear

Leaf Spring

When Fitting the Below Springs, Longer U-Bolts are Required.

4 + 2 Leaves
Raised Height (50mm Lift)
Up to 100Kg Constant Load

Part Number

FORD-014-R

Availability

5 + 2 Leaves
Heavy Duty
Raised Height (50mm Lift)
300Kg Constant Load

Part Number

FORD-015-R

Availability

Shock Absorber

Twin Tube Nitro-Gas

Part Number

GS45-915A

Availability

Spring & Shackle Bush Kit

Front of Front

Part Number

PB19-1504

Availability

Rear of Front

Part Number

PB19-1505

Availability

U-Bolt Kit

Kit Contains:
2 x UB19-922

Part Number

UB19-922K

Availability
