Suitable For

Type:

BT-50

Model:

Year:

Mid 2020 on

Detail:

4x4
3" Front, 2" Rear

Download Catalogue Page

Coil Springs: Sold in Pairs. Torsion Bars: Sold in Pairs. Prices are subject to change without notice. *Raised Height Measurements are Listed as a Guide Only

Front

Coil Spring

Linear Rate
Raised Height (75mm Lift)
0-50Kg

Part Number

C59-314

Availability

Linear Rate
Raised Height (75mm Lift)
50-100Kg

Part Number

C59-318

Availability

Shock Absorber

Twin Tube Nitro-Gas

Part Number

GS21-472

Availability

IFP Monotube Shock
Adjustable Spring Seat Height
X = 195mm / 7.48”

Part Number

IMS21-50472

Availability

X - Centre of Eye to Spring Seat

Monotube Remote Reservoir
(3-Way Adjustable)
Adjustable Spring Seat Height
X = 195mm / 7.48”

Part Number

MRA21-A472-2

Availability

X - Centre of Eye to Spring Seat

Bump Stop

Replacement Bump Stop
Progressive Adjustable 0-20mm Extension

Part Number

BS59-560

Availability

Replaces Original Bump Stop.
If Exceeding Listed Spring Seat Heights This MUST Be Used To Prevent Coil Bind.

Control Arm

Upper Control Arm

Forged Aluminium (Pair)
Adjustable Camber
Increased Castor
With Ball Joint

Part Number

UCA21-216K

Availability

Strut Top Cap

Part Number

SC59-002

Availability

Diff Drop Kit

Part Number

DD21-590K

Availability

Decreases CV Angle

Rear

Leaf Spring

3 + 3 Leaves
Medium Duty
Raised Height (40mm Lift)
Up to 100Kg Constant Load

Part Number

L21-140-R

Availability

4 + 3 Leaves
Heavy Duty
Raised Height (40mm Lift)
250Kg Constant Load (Recommended)

Part Number

L21-141-R

Availability

5 + 3 Leaves
Super Heavy Duty
Raised Height (40mm Lift)
450Kg Constant Load

Part Number

L21-142-R

Availability

2 + 1 Leaves (Parabolic)
Raised Height (50mm Lift)
Up to 70Kg Constant Load
Comfort Option

Part Number

L21-182-RP

Availability

Shock Absorber

Suits Standard Springs Only

Twin Tube Nitro-Gas

Part Number

GS43-801

Availability

IFP Monotube Shock

Part Number

IMS21-50471

Availability

Fit Only With Raised Springs

Twin Tube Nitro-Gas
(Long Travel)

Part Number

GS43-081B

Availability

WA21-584K Must Be Fitted With These Shock Absorbers

IFP Monotube Shock
(Long Travel)

Part Number

IMS43-50081B

Availability

WA21-584K Must Be Fitted With These Shock Absorbers

Monotube Remote Reservoir
(3-Way Adjustable)

Part Number

MRA43-A081B

Availability

Spring & Shackle Bush Kit

Kit Contains:
2 x PB59-1503
4 x PB59-1530
4 x PB21-1555

Part Number

PB21-1111K

Availability

U-Bolt Kit

Suits L21-140-R
Kit Contains:
2 x UB59-453-2

Part Number

UB59-453-2K

Availability

Suits L21-141-R
Kit Contains:
2 x UB59-437

Part Number

UB59-437K

Availability

Suits L21-142-R
Kit Contains:
2 x UB59-437

Part Number

UB59-437K

Availability

Suits L21-182-RP
Kit Contains:
2 x UB59-437

Part Number

UB59-437K

Availability

Shackle Kit

Greasable: Fit in Pairs

Part Number

SK21-065

Availability

Shackle Pin

Greasable: Fit in Pairs

Part Number

SP59-060

Availability

Brakeline Extension

Brakeline Extension Kit

Part Number

WA21-584K

Availability

Must Be Fitted With GS43-081B, IMS43-500818 & MRA43-A081B
