Suitable For

Type:

Navara / Frontier

Model:

D41, USA

Year:

2021 on

Detail:

Leaf Spring Rear

Download Catalogue Page

Coil Springs: Sold in Pairs. Torsion Bars: Sold in Pairs. Prices are subject to change without notice. *Raised Height Measurements are Listed as a Guide Only

Front

Coil Spring

Linear Rate
Raised Height (50mm Lift)
40-70Kg

Part Number

C45-256

Availability

Linear Rate
Raised Height (65mm Lift)

Part Number

C45-256

Availability

Linear Rate
Raised Height (65mm Lift)
40-70Kg

Part Number

C45-254

Availability

Linear Rate
Raised Height (75mm Lift)

Part Number

C45-254

Availability

Linear Rate
Raised Height (75mm Lift)
60-100Kg

Part Number

C45-442

Availability

Shock Absorber

IFP Monotube Shock
Adjustable Spring Seat Height
X = 106mm / 4.17"

Part Number

IMS45-50648

Availability

X - Centre of Eye to Spring Seat

Monotube Remote Reservoir
(3-Way Adjustable)
Adjustable Spring Seat Height
X = 106mm / 4.17"

Part Number

MRA45-A648

Availability

X - Centre of Eye to Spring Seat

Bump Stop

Replacement Bump Stop
Progressive Adjustable 0-35mm Extension

Part Number

BS59-560

Availability

Replaces Original Bump Stop.
If Exceeding Listed Spring Seat Heights This MUST Be Used To Prevent Coil Bind.

Control Arm

Upper Control Arm

6082 Forged Aluminium (Pair)
Adjustable Camber
Increased Castor
Rubber Bushes
with Ball Joint
(Long Travel)

Part Number

UCA45-205K

Availability

Strut Top Cap

Part Number

SC45-004

Availability

Rear

Leaf Spring

3 + 2 Leaves
Raised Height (50mm Lift)
Medium Duty
Up to 70Kg Constant Load

Part Number

L45-002-R

Availability

4 + 2 Leaves
Raised Height (50mm Lift)
Heavy Duty
250Kg Constant Load

Part Number

L45-003-R

Availability

5 + 2 Leaves
Raised Height (50mm Lift)
Super Heavy Duty
380Kg Constant Load

Part Number

L45-004-R

Availability

4 + 2 Leaves
Raised Height (75mm Lift)
No Load

Part Number

L45-003-R

Availability

5 + 2 Leaves
Raised Height (75mm Lift)
150-200Kg Constant Load

Part Number

L45-004-R

Availability

Shock Absorber

IFP Monotube Shock (IMS)

Part Number

IMS45-50653

Availability

Monotube Remote Reservoir
(3-Way Adjustable)

Part Number

MRA45-A653

Availability

Spring & Shackle Bush Kit

Kit Contains:
2 x PB59-1529
4 x PB45-1531
4 x PB45-1507

Part Number

PB45-1095K

Availability

U-Bolt Kit

Select Correct U-Bolt to Suit Appropriate Spring Selection

Suits L45-002-R
Kit Contains:
2 x UB59-667

Part Number

UB59-667K

Availability

Suits L45-003-R
Kit Contains:
2 x UB59-453-2

Part Number

UB59-453-2K

Availability

Suits L45-004-R
Kit Contains:
2 x UB59-453-2

Part Number

UB59-453-2K

Availability

Shackle Kit

Greasable: Fit in Pairs

Part Number

SK45-054

Availability

Shackle Pin

Greasable: Fit in Pairs

Part Number

SP59-060

Availability
