Suitable For

Type:

Landcruiser

Model:

80 Series - FJ80, FZJ80, HZJ80 (Confirm Build Date)

Year:

08/1991 to 1998

Detail:

Station Wagon

Download Catalogue Page

Coil Springs: Sold in Pairs. Torsion Bars: Sold in Pairs. Prices are subject to change without notice. *Raised Height Measurements are Listed as a Guide Only

Front

Coil Spring

Linear Rate
Standard Height

Part Number

C59-174

Availability

Variable Rate
Standard Height

Part Number

C59-210V

Availability

Linear Rate
Raised Height (40mm Lift)
Comfort Spring - Petrol Only
Up to 50Kg

Part Number

C59-234

Availability

Variable Rate
Raised Height (40mm Lift)
Up to 50Kg

Part Number

C59-220V

Availability

Variable Rate
Raised Height (40mm Lift)
50-100Kg

Part Number

C59-222V

Availability

Linear Rate
Raised Height (45mm Lift)
Up to 50Kg
(Recommended)

Part Number

C59-168

Availability

Linear Rate
Raised Height (45mm Lift)
Up to 100Kg

Part Number

C59-166

Availability

Linear Rate
Raised Height (60mm Lift)

Part Number

C59-166

Availability

Shock Absorber

Twin Tube Nitro-Gas

Part Number

GS59-683

Availability

IFP Monotube Shock (IMS)

Part Number

IMS59-60683

Availability

Monotube Remote Reservoir
(3-Way Adjustable)

Part Number

MRA59-A683

Availability

Steering Damper

Heavy Duty (Big Bore)
Complete with Fittings

Part Number

SD59-824

Availability

Adjustable Performance Remote Reservoir Damper�

Part Number

SS59A824

Availability

Castor Kit

Raising Vehicle Will Effect Castor Angle. A Wheel Alignment is Recommended to Determine if a Castor Kit is Required.

Adjustable Front Radius Arm Castor Kit
Angle Settings: ±0° or ±2.5°
4 x Polyurethane Eccentric Bushes

Part Number

PB59-503K

Availability

Fixed Rubber Front Radius Arm Castor Kit
Angle Setting: ±2.5°
4 x Rubber Eccentric Bushes

Part Number

RB59-522K

Availability

Radius Arm Bush

0 Degree Standard Radius Arm Bush Kit
Arm to Diff
4 x Rubber Bushes

Part Number

RB59-536K

Availability

Arm to Chassis Bush Kit
2 x Rubber Bushes

Part Number

RB59-534K

Availability

Coil Spacer

5mm

Part Number

PS59-4001

Availability

10mm

Part Number

PS59-4002

Availability

20mm

Part Number

PS59-4003

Availability

30mm

Part Number

PS59-4004

Availability

Under Body Bush Kit

SEE REAR UNDER BODY BUSH KIT

Rear

Coil Spring

Linear Rate
Standard Height

Part Number

C59-243

Availability

Variable Rate
Standard Height

Part Number

C59-221V

Availability

Variable Rate
Raised Height (45mm Lift)
Comfort Spring - Petrol Only
No Load

Part Number

C59-269V

Availability

Linear Rate
Raised Height (45mm Lift)
Up to 100Kg Constant Load
(Recommended)

Part Number

C59-169

Availability

Variable Rate
Raised Height (45mm Lift)
Up to 100Kg Constant Load

Part Number

C59-223V

Availability

Linear Rate
Raised Height (50mm Lift)
350Kg Constant Load

Part Number

C59-171

Availability

Linear Rate
Raised Height (60mm Lift)
Up to 100Kg Constant Load

Part Number

C59-167

Availability

Shock Absorber

Twin Tube Nitro-Gas

Part Number

GS59-682

Availability

IFP Monotube Shock (IMS)

Part Number

IMS59-60682

Availability

Monotube Remote Reservoir
(3-Way Adjustable)

Part Number

MRA59-A682

Availability

Bump Stop

Hydraulic Bump Stop

Replaces OEM Inner Coil Bump Stops For Smoother Bottom Out And Reduced Bucking

Height Adjustable - Can Be Used As Bump Stop Extension Kit

May Require Extra Bump Stop Extensions For Rubber Outer Bump Stops

Threaded Body
56mm Diameter
46mm Travel
(0"-4" Shocks)

Part Number

HBS56-009

Availability

Threaded Body
56mm Diameter
50mm Travel
(5"+ Shocks)

Part Number

HBS56-006

Availability

Hydraulic Bump Stop Mounting Kit

Mounting Kit
(Bolt On)

Part Number

HBS59-019FK

Availability

Brake Adjuster

Recommended when Raising Vehicle

Part Number

BA45-005

Availability

Coil Spacer

10mm

Part Number

PS59-4005

Availability

15mm

Part Number

PS59-4006

Availability

30mm

Part Number

PS59-4007

Availability

Under Body Bush Kit

Kit Includes Front & Rear Under Body Bushes

Kit Contains:
2 x Front Radius Rod to Chassis Bush
4 x Front Leading Arm Bush
2 x Front Panhard Rod Bush
4 x Rear Upper Control Arm Bush
4 x Rear Lower Control Arm Bush
2 x Rear Panhard Rod Bush

Part Number

PB59-1258K

Availability
